Phoenix Gold GX 12" 2x4 Ohm
Lignende produkter
Dual Cone Design- To strengthen the rigidity of the woofer’s cone body to minimize the distortion while increasing the handling of high pressure produced in the subwoofer enclosure
Magnetic FEA High Efficiency Motor- provides highest possible, efficient motor design
Thermal Efficient Design via Vented Motor- providing better thermal efficiency, reduces motor compression and extended low frequency response
Reduced Motor Compression via Vented Motor
Double Looped and Sleeved Lead Wires for High Excursion- reduces wire roping and allows high excursion, increased flexibility and long life
Special Push Type Terminals with Short Prevention
BEEF’ed Up- Bent Edge Enhanced Frame- minimizes overall resonance and provides accurate sound with less distortion
Linear Surround Technology- for high excursion
Black Anodized Voice Coil Former- heat dissipation
CFL³ Technology Voice Coil- 3x more structurally rigid, prolonging the life of voice coil
MLB Collar Technology- enables micro level bonding with cone & spider for increased strength
Linear Long Throw Spider Suspension- for increased output and power handling
Large 2.5” Voice Coil- GX12D4, GX12D4, GX10D4, GX10D2 and 2” Voice Coil for GX8D4, GX8D2
Removable Gasket for adding grills
G112 Grill (GX12D4 / GX12D2) G110 GX10D4 / GX10D2)
Nominal Impedance
3.50 ohms
DC Resistance (Re)
7.00 ohms
Resonance Frequency
21.80 Hz
Piston Area (Sd)
0.0499 m2
Force Factor (BL)
20.77 Tm
Mechanical Q Factor (Qms)
3.25
Electrical Q Factor (Qes)
0.34
Total Q Factor (Qts)
0.31
Sensitivity 1W/M (SPL)
87.72 dB
Mechanical Compliance (Cms)
0.35 mm/N
Moving Mass (Mms)
152.42 g
Linear Excursion (Xmax)
9 mm
Volume Acoustic Compliance (Vas)
121.48 Ltr
4.29 cu ft
Reference Efficiency (NO.)
0.36%
Nominal Power (Pe)
400 Watts
Peak Power
800 watts
Frequency Response
30-500 Hz
Voice Coil Diameter
2.5 in/63.5 mm
Displacement
0.10 cu ft/2.72 Ltr
Overall Diameter 12.50 in/317.50 mm
Cut Out Diameter
11.25 in/285.75 mm
Mounting Depth
6.26 in/159 mm
