DD Audio SS4.1300-24V

3 247,2 NOK / Stykke

24V 4-Channel amplifier D class amplifier Very small size Efficient heat sink 4 x 325W / 2 x 650W
Les mer

SS4.1300-24V DD Audio

Lignende produkter

Excursion SXA 55-24 PRO
Excursion SXA 55-24 PRO
4 395,6 NOK / Stykke
Audio System CO-75.4 24V
Audio System CO-75.4 24V
2 635,6 NOK 2 459,6 NOK / Stykke
-7%
Audio System R 110.4 24V
Audio System R 110.4 24V
3 867,6 NOK 3 515,6 NOK / Stykke
-9%

The new SS4.1300 brings next level power to the multi-channel wing of the SS Series amplifier line-up. With nearly 200 watts per channel at 4 Ohms and over 325 Watts at 2 Ohms, these compact amps will drive pro audio and motorcycle systems to new extremes with exceptional sound quality.

The SS amplifiers quickly earned a reputation for big clean power from a small package. Their high speed, high current class D designs offer high power and superior sound quality in compact footprints. The classic DD AUDIO style heat sink provides max cooling thanks to 50% more side wall thickness than industry norms with extra long fins to increase surface area. As with all DD amps, all major components are name brands use higher current mosfets and output devices, increased power capacitors, a more powerful transformer, plus improved venting and PCB with twice the thermal capability.

These new high-end mini amps are state of the art, no compromise designs yielding the best sound with unparalleled power to size ratio. The transformation is physically tangible and audibly undeniable.

Teknisk Information

Operating Voltage:
Test Voltage:
Input Channel(s): 4
Output Channel(s): 4
Continuous Wattage @4ohm: 180 x 4 / 650 x 2
Continuous Wattage @2ohm: 325 x 4
Continuous Wattage @1ohm:
Max Current Draw (Amps): 150
RCA Input Voltage Sensitivity: 6 - 0.25
RCA Input S/N: 95
High-Level Input Voltage Sensitivity: 20 - 1.1
Damping Factor: 100
THD: 1.0%
Frequency Response (Hz): 20 - 20k
Sub-Sonic Filter:
High Pass Filter: 35 - 600
Low-Pass Filter: 35 - 600
Remote Control:
Power Wire Gauge: 4
Speaker Wire Gauge: 14
Dimensions (Inches): 6.25 x 4.6 x 2
Dimensions (MM): 159 x 117 x 50
Shipping Weight (Lbs):
