B2 Audio ZERO "Osprey" 9K Watts 1-Ohm Monoblock Class-D Half Bridge Amplifier

Specifications:

• Total Watts:  9000 Watts

12V <1% THD

• RMS Power @ 4 ohm: 2200
• RMS Power @ 2 ohm: 3800
• RMS Power @ 1 ohm: 6000

13.8V <1% THD

• RMS Power @ 4 ohm: 3000
• RMS Power @ 2 ohm: 5500
• RMS Power @ 1 ohm: 8000

14.4V <1% THD

• RMS Power @ 4 ohm: 3400
• RMS Power @ 2 ohm: 5900
• RMS Power @ 1 ohm: 8500

16V <1% THD

• RMS Power @ 4 ohm: 3500
• RMS Power @ 2 ohm: 6000
• RMS Power @ 1 ohm: 9000
• Circuit Configuration: Class D Half Bridge
• Frequency response: 10 Hz ~ 300 Hz
• Signal to noise Ratio: >95 dB
• Input Sensitivity: 5V ~0.2V
• Crossover Circuit: 24 dB / OCT
• Low Pass Crossover: 35 Hz ~ 250 Hz
• Subsonic Crossover: 10Hz ~ 50 Hz
• Damping factor: >400
• Power/Ground Terminal Gauge:  0 Ga
• Speaker Terminal Gauge: 4 Ga
• Fuse Rating: 800A

Measurements:

• Length: 24.5" / 622mm
• Width: 9.25" / 235mm
• height: 2.67" / 68mm
